FLASSMER RR 4.2 - 7 Boat Support

Operator’s Handbook for
Fassmer rescue boats Type RR 4.2
Document 40.0420-019.01.01.0 Art. No. 135897 Mod. 0 Lange/WZ 03.11.2006
28
7. Boat support
The standard boat support (Fig. 23) consists of 2 supports with centre pillar
for keel support so that outboard engine can be hinged down. On shipside
there is an adjustable bearing arm which will be adapted to boat shape. Fix
the adjustment by welding 2nd stanchion to deck (refer to boat support
drawing).
On launching side a moveable bearing arm with attached lashing belt is
fitted. The belt has to run over the boat and will be tightened with a s/s
ratchet buckle on inside.
For launching release the belt and the moveable outside arm falls down to
allow swing out and launching of the boat without lifting before
!
Danger:
Ensure that boat is connected tight with davit before releasing
lashing, otherwise boat might drop down from boat support.
Fig. 23
