LAMPS AND BULBS
Interior - 12-volt
Bedroom reading light ......................1141, 12-volt
Cabover reading light .......................1141, 12-volt
Halogen................................................G4, 12-volt
Range hood......................DWE 40w incandescent
Exterior - 12-volt
Back-up lights...................................1156, 12-volt
Entry step light ...................................194, 12-volt
Front clearance lights .........................194, 12-volt
License plate light ................................67, 12-volt
Luggage compartment light..............1141, 12-volt
Porch lights.......................................1003, 12-volt
Rear clearance lights .........................194, 12-volt
Side marker lights...............................194, 12-volt
Stop/turn/taillights......................P21/5W OSRAM
SYLVANIA #7528
or PHILIPS #12499
MOTOR HOME FUSES AND
CIRCUIT BREAKERS
The 120-volt circuit breakers and 12-volt fuses
are located on three separate panels. The pur-
pose of these three panels is to provide electrical
circuit breakers and fuses to interrupt current
flow if a circuit is overloaded.
1. 120-volt House Electrical — This electri-
cal panel is located under the bed. This
panel is very similar to a residential panel
with resettable breakers.
2. Fleetwood Automotive 12-volt System —
This panel is located in the under floor
luggage compartment next to the entry step.
This electrical center contains battery dis-
connect systems, entry step, fog light, and
some other automotive circuitry.
3. 12-volt Chassis Fuses — This electrical
panel is located under the driver’s seat.
CAUTION
Before relamping, disconnect power source by remov-
ing fuse or placing circuit breaker and control switch in
OFF position.
Halogen bulbs operate at extremely high tempera-
tures and pressures and will shatter if not handled cor-
rectly.
Always use a soft dry cloth or cotton gloves when han-
dling halogen bulbs.
Do not touch glass area with bare hands. If bulb is
touched with bare hands, wipe the bulb clean with rub-
bing alcohol.
Do not use near flammable or combustible materials
and/or objects which may be sensitive to fading or dry-
ing.
Use bulbs designed or specific by manufacturer as to
style, wattage and voltage.
!
NOTE
Consult Chassis Operator’s/Owner’s Guide/Manual
for automotive lamp replacement on chassis cab. This
would include headlamps, turn signals and running
lamps.
PULSE-ICON INFORMATION
04-1
WARNING
Do not install 12-volt fuses or 120-volt breakers with
amperage ratings greater than that specified on the
device or label. Doing so constitutes a fire hazard.
!
