To make a secure connection, use a small
screwdriver to press down on the spring tension
clamp of the relevant socket (see Fig. 3) and feed
the unisolated and twisted end of the wire into
the relevant plug socket. Remove the screwdriver
and the wire will be retained in place by spring
tension.
A) Here are the plug connections for connecting
up a FLEISCHMANN turntable for 2-rail
operations:
Two wires from the track layout are connected
into sockets 1 and 2 of the plug "right hand track
(1)" and "left hand track". The pair of two
yellow wires (coming from the turntable tracks)
are then connected into sockets 3 and 4. The red
wire from the turntable is connected into socket
5, the grey wire from the turntable is connected
into socket 6 and the remaining yellow wire from
the turntable is connected to socket 7.
B) For connecting up a FLEISCHMANN turntable
6652 for 3-rail AC operation (Märklin system),
here are the plug connections:
The two wires from the track layout are
connected into sockets 1 and 2 of the plug
"common track (1)" and "centre rail (2)". The
pair of two yellow wires are then connected to
socket 3, the white wire of the centre rail into
socket 4. The red wire from the turntable is
connected to socket 5. The grey wire is
connected to socket 6 and the yellow wire into
socket 7.
Advice: The wiring instructions are also indicated
on the rear of the equipment!
C) When connecting to the Märklin turntable
7286 for 3-rail AC operation, the wiring is as
follows:
First of all, cut off all of the "old" plugs on the
connecting wires of the turntable.
Connect the wires from the layout into sockets 1
and 2 of the 7-pole plug "common rail (1)" and
