4. Appendix
This appendix shows some of the specialities of
the TURN-CONTROL.
Errors will be indicated in the display with this symbol
" ! " and one of the following code numbers.
Indicating:
1 When programming, the selected track exit is
already allocated.
2 The equipment was tuned off by interruption
of the power feed and is in the intermediate
position awaiting a new switch on.
3 When rotating the bridge the rest point was
reached too soon.
4 When rotating the bridge the rest point was
reached too late.
5 In DCC or LocoNet operation wrong exit
selected.
6 Short Circuit
7 No turntable connected, likewise
– connection broken.
To the table beneath: For controlling, the adresses 200 to 299 are
to be used, the data format is “DC“. Refer to TWIN-CENTER under
„Basic settings-> switch settings of dig. addr. of virtual electrical
accessory decoders“ (see TWIN-CENTER-manual).
TURN-CONTROL-DCC-addresses of the track exits.
48
Digit. Addr. exit 1 exit 2 exit 3 exit 4
50 200
51 201 202 203 204
52 205 206 207 208
53 209 210 211 212
54 213 214 215 216
55 217 218 219 220
56 221 222 223 224
57 225 226 227 228
58 229 230 231 232
59 233 234 235 236
60 237 238 239 240
61 241 242 243 244
62 245 246 247 248
63 249 250 251 252
64 253 254 255 256
65 257 258 259 260
66 261 262 263 264
67 265 266 267 268
68 269 270 271 272
69 273 274 275 276
70 277 278 279 280
71 281 282 283 284
72 285 286 287 288
73 289 290 291 292
74 293 294 295 296
75 297 298 299
