2.4 Exit track Programming
As the second step
, you must now put
into the TURN-CONTROL the actual
track exit positions which you have
on your layout, for example, with
4 exit tracks (Nos. 1 to 4).
In principle, you can program exits without even
having the turntable connected.
➜ Press the green (menu) key “SEL“.
The indication will change from "SEL" to "Pro"
(Programming, Fig. 8).
In our example,
the first track exit is in the position
at "9 o’clock", with the bridge in the correct
position!
Advice: If not, turn the red knob to the desired
position so that the bridge symbol in the display
turns with it.
➜ To confirm the selection, press the central green
key or the red knob. From now on, in this
manual we will be calling that “confirm“.
The left hand section of the bridge symbol will
now blink and a tiny strip next to the bridge hut
36
Fig. 9 1. Create 1st exit
Fig. 8 Reach position
1
2
3
4
