Flex CS 62 18.0-EC Original Operating Instructions

CS 62 18.0-EC
18
This may significantly decrease the exposure
level over the total working period. Identify
additional safety measures to protect the
operator from the effects of vibration such as:
maintain the tool and the accessories, keep
the hands warm, organisation of work
patterns.
CAUTION!
Wear ear protection at a sound pressure
above 85 dB(A).
Technical specifications
CS 62 18.0-EC
Machine type Hand circular saw
Battery Ah 5
Charging time (Battery 5 Ah) min max. 45
Idling speed r.p.m. 5,000
Saw blade mounting hole mm 20
max. saw blade-diameter mm 165
max. cutting width mm 1.6
max. blank thickness mm 1.0
max. cutting depth mm 62
max. mitre cut 50°
Weight according to “EPTA Procedure 01/2003”
(with battery 5 Ah)
kg 3.9
Weight battery kg 0.72
Angle presetting 22.5°, 45°, 50°

Flex CS 62 18.0-EC Specifications

General

Voltage	18 V
Blade Diameter	165 mm
Cutting Depth at 90°	57 mm
Saw Blade Bore	20 mm
Bevel Range	0° to 50°
