Flex CS 62 18.0-EC User Manual

CS 62 18.0-EC
24
 Attach wing screw/clamping bracket/
spring for mounting the parallel stop (1.).
 Insert parallel stop and set to required
width (2.).
 Tighten the wing screw (3.).
Working with the power tool
CAUTION!
After the power tool has been switched off,
the saw blade continues running briefly.
When the rotating saw blade touches
the workpiece, the power tool may recoil.
NOTE
Excessive feed reduces the performance
of the power tool, impairs the cutting quality
and reduces the service life of the saw blade.
Sawing along a scribe mark
 Connect extraction hose.

Set cutting depth to the required dimension.
 If required, set mitre angle.
 Switch on dust extraction system.
 Hold the handle with your right hand.
 Place saw bench on the workpiece.
 Switch on saw and wait until the saw
blade has reached the maximum speed.
 Slowly feed the saw along the material.
NOTE
The cut marks on the saw bench show the
position of the saw blade for a right-angle cut.
 Feed the saw evenly through the material.
 After cutting:
– Switch off the saw. Saw blade continues
running briefly!
– When the saw is lifted, the saw blade
returns to the initial position and the
guard is locked.
 At the end of work:
Thoroughly clean the electric power tool
and accessories.
Filter:
NOTE
To process large workpieces or to cut straight
edges, you can also attach a bar or similar
implement to the workpiece and guide the
circular saw with the saw bench along this
auxiliary stop.

Flex CS 62 18.0-EC Specifications

General

Voltage	18 V
Blade Diameter	165 mm
Cutting Depth at 90°	57 mm
Saw Blade Bore	20 mm
Bevel Range	0° to 50°
