Flex CS 62 18.0-EC User Manual

CS 62 18.0-EC
23
 To remove, press the release button (1.)
and pull out the battery (2.).
CAUTION!
Protect the battery contacts when the
battery is not being used. Loose metal parts
may short-circuit the contacts –
Explosion and fire hazard!
Battery state of charge
 Press the button to check the state of
charge at the state of charge indicator
LEDs.
The indicator goes out after 5 seconds.
If one of the LEDs flashes, the battery must
be recharged. If none of the LEDs light up
after the button is pressed, the battery is
faulty and must be replaced.
Switching on and off
CAUTION!
For reasons of safety the switch is not
locked and must be held down during
sawing.
The switch interlock prevents the power tool
from being switched on unintentionally.
Initially always switch on saw in working
position.
 Press up and hold down the switch
interlock (1.).
 Press and hold down the switch (2.).
 Release switch interlock (when the saw
has been plunged).
Switching off:
 Release the switch.
Parallel stop
WARNING!
Remove the battery before carrying out any
work on the power tool.
NOTE
Before the saw can be placed in the
supplied transportation case, the parallel
stop must be removed.
The parallel stop can be attached on the left
or right in the direction of thrust of the saw.

Flex CS 62 18.0-EC Specifications

General

Voltage	18 V
Blade Diameter	165 mm
Cutting Depth at 90°	57 mm
Saw Blade Bore	20 mm
Bevel Range	0° to 50°
