Flexicon PD22I - Connecting Multiple Pd22 Ps to Flexnet; Change of Voltage

INSTRUCTION HANDBOOK
PD22I / PD22P
PD22IP IH EN 74-125-102 v1.04
Page 19 of 20
10.3 Connecting multiple PD22P’s to Flexnet
Fig. 10.3
10.4 Change of voltage
200/240 V AC
100/127 V AC
Brown
Orange
Brown
Orange + Brown
Red + Brown
Blue
Black
Blue
Black + red
Fig. 10.4
The PD22 can be converted to accept another supply voltage.
The conversion can be made inside the machine by moving the cables of the transformer
clamps.
BLUE
YEL/GR.
BROWN
WHITE BLACK
BROWN
NET plug on MC12/
MC12P
1
16
1
16
BLUE
YEL/GR.
BROWN
BLUE
YEL/GR.
BROWN
WHITE BLACK
BROWN
WHITE BLACK
BROWN
LINE
EARTH
NEUTRAL
1
16
4
3
1
2
Drive 1 Drive 2 Drive 3
Connection of PD12P's in Flexnet
