Flexit CI 70 - Technical data

25
Flexit GO
6. Technical data
6.1. MECHANICAL DIMENSIONS
89 mm
21 mm
14.4 mm
A6V10733771M01
SS
SS

SS
SS
SS
SS
<'







3


133 mm
6.2. SPECIFICATION
General data
Color Signal white (RAL9003)
Weight 150g
Power supply
*
Operating voltage KNX / PL-Link DC 21...30 V
Max power consumption 7...10 mA
Interfaces
Type of port between room automation
station and room operator unit
KNX / PL-Link
Baud rate 9.6 kbps
Protocol KNX PL-LINK
Standard KNX plug Wire diameter 0.8 mm, max. 1.0 mm
Cable type 2-core twisted pair, stranded, solid
Single cable length (from room automation
station to room operator unit)
<1000 m
Section 0,5…1,5 mm²
Bus line polarity PL+,PL-
Bus terminating resister not required
Sensor data
Temperature Sensor Measuring element NTC resistance sensor
Measuring range 0..50 °C
Measuring accuracy (5...30°C) ±0.8 °C
Measuring accuracy (25°C) ±0.5 °C
$PELHQWFRQGLWLRQVDQGSURWHFWLRQFODVVLȴFDWLRQ
Housing Protection IP30
