Flexit CI 70 - Mechanical design

4
CI 70
1 Gasket for panel mounting
2 Base plate
• with screw holes for all common conduit oxes
• with gaining channels for wiring from center, up, or
bottom
3 Operator unit
1. Scope
• The CI 70 operates control functions, such as fan and
temperature control
• The CI 70 communicates with 2-wire interface to the
controller through KNX PL-Link
2. Mechanical design
1 2 3
!
National safety regulations
Failure to comply with national safety
regulations may result in personal
injury and property damage
• Observe national provisions and
comply with the appropriate safety
regulations.
The subsections include important
information that is either decisive
for the sale or is essential for
engineering.
