Flexit S3 R - 12 Adjustment Curves External Kitchen Hood; Basic Ventilation S3 R;S3 RK; Forced Ventilation S3 R

25
12 Adjustment Curves External Kitchen Hood
12.1 Basic Ventilation S3 R
12.2 Forced Ventilation S3 R
S3 R
0 - Open = Number of rings removed
100/150/200 Pa = Total duct resistance for the extract air and exhaust
air side
Lw (A) measured 1 m from the kitchen hood varies between 46 and 48
dB(A) throughout the measuring area
S3 R/S3 RK
S3 R
Min. - Max. = Damper position
dB = Lp(A) measured 1 m from the kitchen hood in the kitchen landscape.
0
50 Pa
100
150
200
250
300
350
0 20 40 60 80 100 m³/h
Min
Max
6
54
3
2
7
8
9
10
11
35 dB(A)
32 dB(A)
30 dB(A)
25 dB(A)
Pa 125
175
225
275
325
125
175 225
275 m³/h
0
Open
5
4
3
2
1
200 Pa
150 Pa
100 Pa
