In Step 4 you will Configure PowerSDR
A: Run the PowerSDR Setup Wizard
Turn on your FLEX-1500 and run PowerSDR,
by double-clicking on its desktop icon
Alternatively, click on Start, All Programs,
FlexRadio Systems, PowerSDR 2.n.n
(folder), and PowerSDR v2.n.n.
The first time PowerSDR starts up it will run an
optimization routine. Click OK and let the
routine run.
Next the PowerSDR Setup Wizard will start
and a Mobile Warning screen will open. Click
Continue, and you will see a Welcome screen.
Click Next.
You will then be informed that the Wizard is
finished. Click Finish to exit the wizard.
Do not click the Start button just yet.
B: Configure the FLEX-1500 Audio Mixer
Your FLEX-1500 has two inputs (MIC, FlexWire
In) and two outputs (Phones, FlexWire Out).
The Audio Mixer is used to select the ones
you are using and set their audio levels (just
like with a sound card).
Click Mixer in the menu bar of PowerSDR.
Check Mic as the Input to select the front
Mic jack. Check Phones to select the front
Phones jack.
Click the red X at the top right to close.
C: Configure the Antenna Selector
Click Antenna in the menu bar of PowerSDR
to open the Antenna Selection window. Set
the Receive and Transmit Antenna both to
PA.
Click the red X at the top right to close.
D: Click Start
Congratulations! You've now completed all the
steps required to set up your FLEX-1500. In
PowerSDR, click the Start button at the top
left to operate your FLEX-1500.
[Continued on next page]
