© 2013 Flex Radio Systems. All rights reserved.
Remove the Side Panels.
In addition to the instructions below, you may refer to the KB article, How to Remove and Install the FLEX-5000A
Top and Side Panels as a supplementary resource for removing the covers of the FLEX-5000A.
http://kc.flex-radio.com/KnowledgebaseArticle50382.aspx)
a. If you look closely at the side rails you’ll notice little indentations in them. This is to allow you to remove the side
panels.
Figure 1
b. Using a flat blade screwdriver GENTLY pry the side panels off the radio.
Figure 2a Figure 2b
c. Set them aside for later reinstallation.
