Flexwatch FW1173 - Technical Specifications

FW1173 User’s Manual
M4064-00 6 Seyeon Tech Co., Ltd
1.3. Technical Specification
FW1173-DS FW1173-MS FW1173-FS
Hardware
32bit Embedded CPU
NAND Flash 128Mbytes/DDR2: 128Mbytes
Linux version 2.6.xx operating system
Battery backed up real-time clock
Image sensor
1/3” CCD (ICX638,ICX639)
Resolution: 560 TV Lines
S/N ratio: 52dB or more
(AGC OFF, Weight ON)
Electronic shutter speed :
1/60(50) ~ 1/120,000 sec
Sens-up :
AUTO/FIXED/OFF
(selectable limit x2 ~ x256)
White Balance:
ATW/AWC/Manual/Outdoo
r(1800K~10,500K)/Indoor(
4500K ~8500K)
1/3” progressive scan MOS
Active pixels 1280H x
1024V, 1.31M
Effective pixels 1376H x
1070V, 1,47M
Pixel size: 3.75 (H) µm ×
3.75 (V) µm
Color filter Bayer
arrangement of primary
colors: R, G, B
Bit number of internal
ADC: 12 bits
Parallel output: 54 MHz, 12
bits
Output frame rate: 30 fps
1/2.8” progressive scan
CMOS
Active pixels 2080H x
1553V, 3.23M
Effective pixels 2096H x
1561V, 3.27M
Pixel size : 2.5 (H) µm ×
2.5 (V) µm
Color filter Bayer
arrangement of primary
colors: R, G, B
Bit number of internal
ADC: 10/12 bits
Parallel output: 37.125
MHz, 10/12 bits
Maximum frame rate in all-
pixel scan mode: 60 fps
Lens Not included
Minimum illumination
Color: 0.15 Lux (F1.2)
B/W: 0.002 Lux (F1.2)
(Sens-up: x128)
Color: 0.1 Lux(F1.0)
B/W: 0.01 Lux(F1.0) (TDN)
0.02 Lux(F1.0)
(without TDN)
Color: 0.3 Lux(F1.2)
B/W: 0.002 Lux
Video related special
functions
Backlight
(OFF/LOW/MIDDLE/HIGH)
AGC
(OFF/LOW/MIDDLE/HIGH)
Lens (MANUAL/DC)
Shutter
(ESC/MANUAL/FlickerLes
s)
White Balance
(ATW/AWC/MANUAL)
DNR
Day & Night (ON/OFF)
AGC, AWB
Lens (MANUAL/DC)
Shutter (MANUAL/AUTO)
Vertical/Horizontal Flip
Frequency Control (50/60)
Brightness/Contrast/Sharp
ness Control
Day & Night
(AUTO/COLOR/BW)
AGC, AWB, Auto Exposure
Lens (MANUAL/DC)
Shutter (AUTO/MANUAL)
Brightness/Contrast/Sharp
ness Control
Video compression
Motion JPEG
H.264
Video Standards
ONVIF
PSIA
Resolution
720x480, 704x480,
704x240, 352x240,
176x112
1.3M(1280x1024),
HD(1280x720),
VGA(640x352),
CIF(320x176),
QCIF(160x96)
FullHD(1920x1080),
HD(1280x720),
VGA(640x352),
CIF(320x176),
QCIF(160x96)
