ZH-CNZH-CN 简体中文
注意意:封盖存在两种型号,一种是硬
快速速入门指指南
塑料,一种是软橡胶。此图像和以下
请按以下步骤立即开始:
图像显示的是硬塑料型号。
1. 将电池放入电池盒中。
2. 用于预览/保存图像的触发按钮
2. 首次启动热像仪之前,先将电池充电
3. 三脚架接口。需要适配器(额外附
4 小时,或者直到绿色的电池状态
件)
LED 持续亮起为止。
4. 聚焦环
3. 将存储卡插入存储卡插槽中。
5. 红外镜头
4. 按钮以打开热像仪。
左视视图
5. 将热像仪对准目标对象。
6. 旋转聚焦环将热像仪对焦。
7. 拉快门以直接保存图像。
8. 通过执行下列操作之一,将图像移动
到计算机:
取出存储卡并将其插入与计算机连
接的读卡器中。
使用一条 USB mini-B 线缆将计算
机连接到热像仪。
9. 利用拖放操作移动存储卡或热像仪中
的图像。
注意意:您还可以使用随热像仪一起提供的
1. 激光指示器
FLIR Tools 软件将图像移动到计算机。
2. 数码相机照明灯
3. 数码相机
热像像仪部件
4. 接口盖和存储介质:
右视视图
存储卡
视频接口
底视视图
1. 右侧接口盒盖:
USB-A
USB mini-B
电源
1. 用于打开电池盒盖的锁扣。推动可打
开。
© 2011, FLIR Systems, Inc. All rights reserved worldwide.
101
Publ. no. T559524, rev. 014
