910-0001-00-INS -R02 Page 20 of 53
Information contained in this document pertains to a Canadian origin product that is controlled as "dual use" by the Canadian government. However, when in
the United States or possessed by a US person, it may be considered a defense article from the US Government's perspective. US government authorization
may be required for re-transfer to a foreign person. If you have any questions, please contact FLIR's Global Trade Compliance group at
exportquestions@flir.com .
Figure 9 - Radar Installation on Even Terrain - Incorrect Height
Figure 10 - Radar Installation Near Rising Terrain - Correct Radar Position and Tilt Angle
Figure 11 - Radar Installation on Hill Top - Incorrect Tilt Angle
