Technical data24
Data communication interfaces
Interfaces USB-mini, USB-A, Bluetooth, Wi-Fi, Digital Video
Output
METERLiNK/Bluetooth Communication with headset and external
sensors
Wi-Fi Peer to peer (ad hoc) or infrastructure (network)
SD Card One card slot for removable SD memory cards
USB
USB
• USB-A: Connect external USB device
• USB Mini-B: Data transfer to and from PC / un-
compressed colorized video
USB, standard USB 2.0 high speed
Video output
Video out Digital video output (DVI)
Video, connector type HDMI compatible
Radio
Wi-Fi
• Standard: 802.11 b/g
• Frequency range: 2412–2462 MHz
• Max. output power: 15 dBm
METERLiNK/Bluetooth
Frequency range: 2402–2480 MHz
Antenna Internal
Power system
Battery type Rechargeable Li ion battery
Battery operating time
> 2.5 hours at 25°C (+68°F) and typical use
Charging system In camera (AC adapter or 12 V from a vehicle) or
2-bay charger
Charging time 2.5 h to 90 % capacity, charging status indicated
by LED's
Charging temperature 0°C to +45°C (+32°F to +113°F)
External power operation
AC adapter 90–260 VAC, 50/60 Hz or 12 V from a
vehicle (cable with standard plug, optional)
Environmental data
Operating temperature range –15°C to +50°C (+5°F to +122°F)
Storage temperature range –40°C to +70°C (–40°F to +158°F)
Humidity (operating and storage) IEC 60068-2-30/24 h 95% relative humidity +25°C
to +40°C (+77°F to +104°F) / 2 cycles
EMC
• ETSI EN 301 489-1 (radio)
• ETSI EN 301 489-17
• EN 61000-6-2 (Immunity)
• EN 61000-6-3 (Emission)
• FCC 47 CFR Part 15 Class B (Emission)
• ICES-003
Radio spectrum
• ETSI EN 300 328
• FCC Part 15.247
• RSS-210
Encapsulation
IP 54 (IEC 60529)
Shock 25 g (IEC 60068-2-27)
Vibration 2 g (IEC 60068-2-6)
Safety EN/UL/CSA/PSE 60950-1
#T559880; r. AK/36075/36075; en-US
128
