Working with images14
Note The camera must be configured to display a preview image before saving. Select
(Settings) > Save options > Preview image before saving = On.
14.2.2 Procedure
Follow this procedure:
1. To preview an image, push the Autofocus/Save button fully down. This displays the
preview.
2. Manual image adjust mode is now active, and the status icon
is displayed. For
image adjustment instructions, see 14.5 Adjusting an infrared image, page 36.
3. To edit the image, push the joystick. This displays a context menu. For editing instruc-
tions, see 14.4 Editing a saved image, page 35.
4. Do one of the following:
To save the image, push the Autofocus/Save button fully down.
To exit preview mode without saving, push the Back button
.
14.3 Opening a saved image
14.3.1 General
When you save an image, the image file is stored on the memory card. To display the im-
age again, open it from the image archive.
14.3.2 Procedure
Follow this procedure:
1. Push the Image archive button
.
2. Move the joystick up/down or left/right to select the image you want to view.
3. Push the joystick. This will display the image at full size.
4.
Do one or more of the following:
To switch between an infrared image and a visual image, move the joystick up/
down.
To view the previous/next image, move the joystick left/right.
To edit the image, add annotations, display information, or delete the image, push
the joystick. This displays a context menu.
To return to the image archive overview, push the Back button
.
14.4 Editing a saved image
14.4.1 General
You can edit a saved image. You can also edit an image in preview mode.
14.4.2 Procedure
Follow this procedure:
1. Open the image in the image archive.
2. Push the joystick and select
(Edit) from the menu.
3. Manual image adjust mode is now active, and the status icon
is displayed. For
image adjustment instructions, see 14.5 Adjusting an infrared image, page 36.
#T559880; r. AK/36075/36075; en-US
35
