FLIR TG267 User Manual

Specifications
10
Image adjustment Automatic
Image modes
• Thermal MSX® (Multi-Spectral Dynam-
ic Imaging)
• Visible Spectrum
10.4 Measurement Specifications
Object temperature range TG267: –25 ~ +380℃ (–13 ~ +716℉)
TG297: –25 ~ +1030℃ (–13 ~ +1886℉)
TG165–X: –25 ~ +300℃ (–13 ~ +572℉)
Accuracy at ambient temperature: 59 ~95℉
(15 ~ 35℃)
-13℉ ~ 32℉ (-25℃ to 0℃): ± 7.0℉ (±
3.0℃)
32℉ ~ 122℉ (0℃ ~ 50℃): ± 5.0℉ (±2.5℃)
122℉ ~ 212℉ (50℃ ~ 100℃): ± 3.0℉ (±
1.5℃)
212℉ ~ 932℉ (100℃ ~ 500℃): ± 2.5%
932℉ ~ 1022℉ (500℃ ~ 550℃): ± 3.0%
1022℉ ~ 1886℉ (550℃ ~ 1030℃): ± 3.0%
IR Temperature resolution 0.2℉ (0.1℃)
Reading repeatability ± 1 % of reading
Response time 150 ms
IR thermometer measurement
Continuous scanning
Minimum measurement distance 0.85 ft. (0.26 m)
10.5 Measurement Analysis Specifications
Spot meter Center spot (cross-hairs); Programmable
ON/OFF
Color display palettes
Iron, Rainbow, White-hot, Black-hot, Arctic,
and Lava
10.6 Type-K specifications (TG267 only)
Type-K Temperature range of
camera
-22℉ ~ 734℉ (-30.0℃ ~ +390.0℃)
1
Over- and under- range indication OL or —OL display (dashes display if thermocou-
ple is not connected)
#NAS100014; r. AJ/68076/68076; en-US
27

FLIR TG267 Specifications

General

Temperature Range	-25°C to 380°C (-13°F to 716°F)
Field of View	57° × 44°
Battery Life	Up to 5 hours
Thermal Sensitivity/NETD	< 70 mK
Image Frequency	9 Hz
Focus	Focus free
MSX (Multi-Spectral Dynamic Imaging)	Yes
On-Screen Emissivity Correction	Yes
Image File Format	JPEG
Laser Pointer	Yes
Drop Test	2 m (6.5 ft)
Weight	0.394 kg (0.87 lb)
Dimensions	210 × 64 × 81 mm (8.3 × 2.5 × 3.2 in)
Operating Temperature Range	-10°C to 45°C (14°F to 113°F)
Storage Temperature Range	-40°C to 70°C (-40°F to 158°F)
IP Rating	IP54
IR Resolution	160 × 120 pixels
Battery Type	Rechargeable Li-ion battery
Emissivity	Adjustable from 0.1 to 1.0
Image Modes	Thermal, MSX
Storage Media	Internal memory
Spectral Range	8–14 µm
