FLIR TG267 User Manual

Safety
3
3.1 Safety Warnings and Cautions
WARNING
⚠This symbol, adjacent to another symbol indicates the user must refer to the manual for
further information.
WARNING
The instrument’s IP54 rating is only in affect when the top flap (covering the USB-C and
Thermocouple jacks) is completely sealed. Do not operate the instrument with the flap
open, except for charging, PC interface, or Type-K thermocouple use.
CAUTION
Use of controls or adjustments or performance of procedures other than those specified
herein may result in hazardous radiation exposure.
CAUTION
Use extreme caution when the Laser pointer is on.
CAUTION
Do not point the Laser beam toward anyone's eye or allow the beam to strike the eye from
a reflective surface.
CAUTION
Do not use the Laser near explosive gases or in other potentially explosive areas.
CAUTION
Refer to the CAUTION statement label (shown below) for critical safety information.
#NAS100014; r. AJ/68076/68076; en-US
3

FLIR TG267 Specifications

General

Temperature Range	-25°C to 380°C (-13°F to 716°F)
Field of View	57° × 44°
Battery Life	Up to 5 hours
Thermal Sensitivity/NETD	< 70 mK
Image Frequency	9 Hz
Focus	Focus free
MSX (Multi-Spectral Dynamic Imaging)	Yes
On-Screen Emissivity Correction	Yes
Image File Format	JPEG
Laser Pointer	Yes
Drop Test	2 m (6.5 ft)
Weight	0.394 kg (0.87 lb)
Dimensions	210 × 64 × 81 mm (8.3 × 2.5 × 3.2 in)
Operating Temperature Range	-10°C to 45°C (14°F to 113°F)
Storage Temperature Range	-40°C to 70°C (-40°F to 158°F)
IP Rating	IP54
IR Resolution	160 × 120 pixels
Battery Type	Rechargeable Li-ion battery
Emissivity	Adjustable from 0.1 to 1.0
Image Modes	Thermal, MSX
Storage Media	Internal memory
Spectral Range	8–14 µm
