1,6in
40,7mm
4,95in
125,7mm
3,48in
88,5mm
Optical axis
Protective window
IR Lens f=38 mm (24
°
)
3,4in
86,3mm
3,69in
93,7mm
Protective window
IR Lens f=38 mm (24
°
)
1,46in
37mm
1,6in
40,7mm
Protective window
For additional dimensions see page 1
Camera with Protective window
1 2 3 4 5 6 7 8 9 10
1 632 54
A
B
C
D
E
F
G
H
F
C
E
G
D
A
B
-
Scale
1:2
B
Size
Modified
R&D Thermography
2012-04-19
CAHA
Basic dimensions FLIR P6xx
T125460
7(7)
A3
Denomination
Drawn by
Check
Size
Drawing No.
Sheet
7
© 2012, FLIR Systems, Inc. All rights reserved worldwide. No part of this drawing may be reproduced, stored in a retrieval system, or transmitted in any form, or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without written permission from FLIR Systems, Inc. Specifications subject to change without further notice. Dimensional data is based on nominal values. Products may be subject to regional market considerations. License procedures may apply.
Product may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Diversion contrary to US law is prohibited.
