1,6in
40,7mm
5,89in
149,7mm
3,91in
99,3mm
Optical axis
4,34in
110,3mm
4,58in
116,4mm
For additional dimensions see page 1
Camera with Lens IR f=76 mm (12°)
1 2 3 4 5 6 7 8 9 10
1 632 54
A
B
C
D
E
F
G
H
F
C
E
G
D
A
B
-
Scale
1:2
B
Size
Modified
R&D Thermography
2012-04-19
CAHA
Basic dimensions FLIR P6xx
T125460
3(7)
A3
Denomination
Drawn by
Check
Size
Drawing No.
Sheet
7
© 2012, FLIR Systems, Inc. All rights reserved worldwide. No part of this drawing may be reproduced, stored in a retrieval system, or transmitted in any form, or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without written permission from FLIR Systems, Inc. Specifications subject to change without further notice. Dimensional data is based on nominal values. Products may be subject to regional market considerations. License procedures may apply.
Product may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Diversion contrary to US law is prohibited.
