FLIR ThermaCAM SC640

146mm
5,75in
76mm
2,99in
174mm
6,84in
88mm
3,46in
27,3mm
1,07in
121mm
4,76in
411mm
16,19in
125mm
4,92in
179mm
7,05in
163mm
6,42in
4,2mm
0,16in
Lens support Optional
Optical axis
28mm
1,1in
98mm
3,86in
210mm
8,27in
103mm
4,06in
Optical axis
202mm
7,95in
14mm
0,55in
57,6mm
2,27in
46,4mm
1,83in
5mm
- 0,03
+ 0,08
0,2in
- 0,00
+ 0,00
196mm
7,71in
7mm
0,28in
19,5mm
0,77in
UNC 1/4"-20
M6
Optical axis
6,4in
162,5mm
6,63in
168,4mm
For additional dimensions see page 1
Camera with Lens IR f=131 mm (7°) incl support
1 2 3 4 5 6 7 8 9 10
1 632 54
A B
C
D
E
F
G
H
F
C
E
G
D
A B
-
Scale
1:2
B
Size
Modified
R&D Thermography
2012-04-19
CAHA
Basic dimensions FLIR P6xx
T125460
4(7)
A3
Denomination
Drawn by
Check
Size
Drawing No.
Sheet
7
