Flite 2 Series - Fliteboard AIR assembly

20
Fliteboard AIR assembly
1 Unroll Fliteboard AIR bladder face down.
2 Place the rigid core (Flitebox cavity side up) on a flat surface.
3 Slide bladder onto core from front end first.
4 Ensure bladder is well tucked into the recess along the front edge
of the core.
5 Carefully stretch bladder over one rear corner first.
NOTE THAT THE REAR UNDERSIDE EDGES OF THE CORE ARE
DELIBERATELY SHORTER THAN THE TOP FACE TO MAKE FITMENT OF
THE BLADDER EASIER.
Stretch the bladder over the last corner. Again, be careful that the
bladder is positioned evenly and not creased or caught.
6 Check bladder is seated correctly around the core before carefully
flipping the Fliteboard AIR over.
PLACE ON A SMOOTH, SOFT SURFACE TO AVOID SCRATCHING THE
CARBON FINISH ON THE CORE.
WHEN FLIPPING THE FLITEBOARD AIR OVER, BE SURE THAT THE
ORANGE O-RING IS SEATED CORRECTLY AND STAYS IN PLACE.
4
3
5
6
4
3
5
6
4
3
5
6
