Emptying device of the solution tank
Switch with key
Hour meter
TECHNICAL DESCRIPTION
U/M
ruby 45e
ruby 50e
ruby 55e
Cleaning width mm 450 500 550
Squeegee width mm 790 790 790
Working capacity, up to sqm/h 1575 1750 1925
Brushes diameter mm 2x235 1x508 2x285
Brushes rpm rpm 432 182 345
Pressure on the brushes kg 22 max 30 max 25 max
Brushes motor W 1000 1000 1000
Type of drive semi-aut. semi-aut. semi-aut.
Maximum gradient 2% 2% 2%
Suction motor W 450 450 450
Suction vacuum mbar 110 110 110
Solution tank l 45 45 45
Recovery tank l 48 48 48
Machine length mm 1102 1205 1140
Machine height mm 1033 1033 1033
Machine width (without squeegee) mm 527 535 586
Weight of the machine (empty) kg 85 89 87
Mains cable (length) m 20 20 20
Power supply V 230 230 230
Frequency rate Hz 50 50 50
Noise level dB(A) 66,3 66,2 66,3
Level of vibration m/sqs 0,45 0,50 0,45
Class I I I
Protection level IP 23 23 23
