How To Set Days On Which Water
Conditioner Is To Regenerate:
How To Set The Time Of Day:
How To Manually Regenerate Your Water
Conditioner At Any Time:
How to Adjust Regeneration Time:
IMPORTANT
SALT LEVEL MUST ALWAYS BE ABOVE WATER
LEVEL lN BRINE TANK.
Press and hold the red button in to disengage the drive
gear. Turn the Iarge gear until the actual time of day is at
the time
of day pointer.
Even thought it takes three hours for this center knob to
complete one revolution, the regeneration cycle of your
unit might be set only one half of this time.
time to ensure the desired regeneration time is correct.
8. Reset the time of day and restore power to the unit.
In any event, conditioned water may be drawn after rinse
1. Disconnect the power source.
4. Locate the regeneration time pointer on the inside of
the 24 hour dial in the cut out.
5. Turn the time plate so the desired regeneration time
aligns next to the raised arrow.
6. Push the red button in and rotate the 24 hour dial.
Tighten each of the three screws.
7. Push the red button and Iocate the pointer one more
3. Loosen each screw slightly to release the pressure on
the time plate from the 24 hour gear.
2. Locate
the three screws behind the manual regeneration
knob by pushing the red button in and rotating the 24
hour dial until each screw appears in the cut out portion
of the manual regeneration knob.
water stops flowing from the water conditioner drain Iine.
The black center knob will make one revolution in the
following approximately three hours and stop in the
position shown in the drawing.
Turn the manual regeneration knob clockwise.
This slight movement of the manual regeneration knob
engages the program wheel and starts the regeneration
program .
Release the red button to again engage the drive gear.
Rotate the skipper wheel until the number “1” is at the red
pointer. Set the days that
regeneration is to occur by
sliding tabs on the skipper wheel outward to expose trip
fingers. Each tab is one day. Finger at red pointer is
tonight. Moving clockwise from the red pointer, extend or
retract fingers to obtain the desired regeneration sched-
ule.
T
I
ME
OF D
AY
Manual
Regeneration
Knob
24 HR. Gear
Service
Position
Indicator
Red Time
Set Button
TO MANUALLY
TO SET TIME OF DAY-
PRESS RED BUTTON AND
TURN LARGE DIAL UNTIL
TIME IS AT ARROW.
START CYCLE
TURN KNOB
CLOCKWISE.
Skipper Wheel,12 Day
(Shows Every Other
Day Regeneration)
Red Pointer
Timer Setting Procedure
MODEL 3200 & 3210 TIMER SERIES
Page 11
