20 Instruction Manual
Features & Specifications
Sensor size DN150..600 MXI PN 10/16 IP67, IP68 (optional)
DN10..150 W PN 16 IP67, IP68 (optional)
Accuracy +/- 0,5% of flow rate >0.5m/s
Repeatability +/- 0,1% of flow rate >0.5m/s
Range 0.1-10m/s
Response Time 3 Selectable levels of damping
Transmitter/Display β-meter remote wall mount IP67
Model No. BETA4 85-265VAC 50/60Hz
BETA3 12-30VDC
Display enclosure
IP67 (NEMA 6) Polycarbonate Wall Mount
125 x 125 x 75mm HxWxD (5” x 5” x 3”)
Power supply 80-240Vac 50/60Hz <5VA
12-30Vdc <5W
Indication Two-line rate and 2 x totals
Displayed 2 x totals selectable resettable/grand total
Configuration Supplied to customers spec or modified on site via easy to use
menu structure with touch keypad
Units Rate units: m/s, l/s, l/m, l/hr, m3/s, m3/m, m3/hr, ft/s, ft3/s, ft3/m,
ft3/hr, USgps, USgpm, USgph, USmgd Total units: cl, dl, dal, hl,
ml, l, m3, Ml, ft3, 103ft3, 106ft3, USG, 103USG, 106USG
Outputs Isolated open collector pulse x 3
24V auxiliary power supply
Isolated active 4-20mA
Communication Modbus RTU RS485 (optional)
Calibration Standard 3-Point calibration certificate
Features Batching control with OCT output
Low Cost
Non-intrusive
No pressure loss
No maintenance
No moving parts
Active empty pipe detection
Integral spike suppression
Password and tamper protection
Error displays for easy diagnostics
Easy to install
Options GSM telemetry
Installation Kit (Bolt sets & gaskets)
Grounding rings (for lined or non-conductive pipe)
Standards ISO 6817 First Edition 1992-12-01 Magflow design, CE Certified,
IEC 60068-2-6 Vibration, IEC-60068-2-27 Shock
