13
Schmidt Armaturen
AI - FlowTop
Disassembly
Step 03
• Twist Special Tool (Ring-nut) on the stem
and put in place slowly
CAU TION !
Ensure it hangs vertically !
• Remove fl at gasket (1.2)
CAU TION !
Remove remains of fl at gasket (1.2) in the body
and on the bonnet.
Do not damage sealing surface !
Reassembly
Step 03
After work step "Reassembly" Step 06
• Insert  at gasket (1.2)
CAUTI ON !
   Usenewatgasket(1.2)!
• Twist Special Tool (Ring-nut) on the stem
and put in place slowly
CAUTI ON !
Ensure it hangs vertically !
