Schmidt Armaturen
AI - FlowTop
Disassambly
Step 03
• Lift bonnet off
CAU TION !
Do not damage stem surface !
• Remove fl at gasket (1.2)
CAU TION !
Remove remains of fl at gasket (1.2) in the body
and on the bonnet.
Do not damage sealing surface !
Reassembly
Step 03
After work step "Reassembly" Step 06
• Insert  at gasket (1.2)
CAUTI ON !
   Usenewatgasket(1.2)!
• Put cover in place
CAUTI ON !
Do not damage stem surface !
