AI - FlowTop
Trim Type
Data Field 3
Disassembly / Reassembly
Perforated plug LOxx1xx
Disassembly / Reassembly
2.1 Screwed seat
2.2 Perforated plug
as described !
RLS-System
AOxx1xx
Disassembly / Reassembly
2.1 Perforated screwed seat
2.2 Perforated plug
as described !
RLS-System
BOxx1xx
Disassembly / Reassembly
2.1 Screwed seat
2.2 Perforated plug
4.1 Cover
as described !
RLS-System
DOxx1xx
Disassembly / Reassembly
2.1 Screwed seat
2.2 Perforated plug
4.1 Cover
as described !
