Schmidt Armaturen
AI - FlowTop
Trim Type
Data Field 3
Disassembly / Reassembly
XStream
PGxx1xx
PHxx1xx
Disassembly / Reassembly
2.1 Screwed seat
2.2 Plug
as described, additionally
however
2.29 Internal ring
2.30 Space bush
2.35 Perforated cage 1
2.36 Perforated cage 2
2.37 Perforated cage 3
2.28 Pressure spring
insert in the sequence shown !
XStream PIxx1xx
Disassembly / Reassembly
2.38 Perforated seat cage
2.2 Plug
as described !
XStream PQxx1xx
Disassembly / Reassembly
2.38 Perforated seat cage
2.2 Plug
as described, additionally
however
2.29 Internal ring
2.30 Space bush
2.35 Perforated cage 1
2.36 Perforated cage 2
2.28 Pressure spring
insert in the sequence shown !
XStream PWxx1xx
Disassembly / Reassembly
2.38 Perforated seat cage
2.2 Plug
as described, additionally how-
ever
2.29 Internal ring
2.30 Space bush
2.35 Perforated cage 1
2.36 Perforated cage 2
2.37 Perforated cage 3
2.28 Pressure spring
insert in the sequence shown !
