Schmidt Armaturen
AI - FlowTop
Data Field 1
The series number is in this eld. It is made up
e.g. as follows:
0620278001001
062 06 = Calendar year 2006
2 = Order ( 1 = Quotation )
0278 = consecutive series number
001 = Item within the series number
001 = ascending quantity within the item
The series number and the "part" required must
always be quoted when ordering Spare Parts.
Alternatively you can order using the part no. in
the Spare Parts List at your own risk.
Telephone: 0043 4242 41181 - 0
e-mail: schmidt@owserve.com
Data Field 2 and 3
These elds clearly identify the:
• Body Type (Page 5)
• Trim Type (Page 30 - 32)
• Bonnet Type (Page 34 - 36)
• Packing Type (Page 61 - 62)
marked in detail. This helps you to nd the steps
described at the end.
Rating plate "Type IT"
Rating plate "Type PB"
4. Disassembling the valve
4.1 Fix the valve on the disassembly table !
4.2 Identify the valve using the rating plate:
A rating plate is tted on every control valve for identi cation. In principle there are
two di erent rating plates, their information content is however identical.
• Rating plate "Type IT" for pneumatic linear actuators with internal air conduction.
• Rating plate "Type PB" for pneumatic linear actuators with external air conduction.
