12-10
Figure 5: Plug Thread Adjustment
(Refer to Step 8 in
"Reassembly" Section)
Plug Stem
Jam Nut
Anti-rotation Pin
Bellows Seal Assembly
Bellows Seal Plug
Stroke + 1/16-inch
1-inch to less stroke
stroke +1/32-inch
(See Table II)
Spring Guide Retainer
should compres
approximately 1/8-inch
