Fluance RT80/RT81/RT81P User Manual
19
Specications RT80 RT81 RT81P
Cantilever Carbon Fiber Aluminum Aluminum
Mount Half inch Half inch Half inch
Frequency Response 20-20,000Hz 20-20,000Hz 20-22,000Hz
Channel Separation 18dB at 1kHz 20dB at 1kHz 20dB at 1kHz
Channel Balance 2.5dB or less at 1kHz 2.0dB or less at 1kHz 2.0dB or less at 1kHz
Load Impedance/
Capacitance
47k Ohms/100pF 47k Ohms/100pF 47k Ohms/100pF
Output Voltage 3.5mV +/–3dB 3. 5mV (+/–3 d B) 4.0mV (+/–3dB)
Weight 5.0g (+/- 0.5g) 5.7g (+/- 0.5g) 6.1g (+/- 0.5g)
Headshell Weight 10.7g 10.7g 10.7g
Recommended Tracking
Force
2.0 g (+/– 0. 5 g)
Vertical Tracking Angle
(Non-Adjustable)
20 degrees 20 degrees 23 degrees
Rubber Belt Specications
Thickness 0.02in (0.6mm)
Width 0.17in (4. 5mm)
Length 21.03in (534.07mm)
Output Specications
Connector RCA (Gold-plated)
Preamp Yes, PHONO/LINE Switchable
Phono Output 3.5mV +/–3dB 3.5mV +/–3dB 4mV +/–3dB
Line Output 140mV (–17dBV)
Ground Terminal Yes
Power Specications
Input 100V-240V AC (50/60Hz)
Output 12V / 500mA
Consumption 1.5W
General Specications
Unit Dimensions
( W x H x D )
16.5” x 5.5” x 13.75”
Unit Weight 5.0 kg (11.02 lb) 6.4 kg (14.1 lb) 6.4 kg (14.1 lb)
Optimal Operating
Temperature
20°C
