Calibration Adjustment
4.7 Save Calibration Data And Exit 4
4-13
Possible error messages.
The following messages can be shown on the Analyzer display:
WARNING: Calibration data not valid.
Save data and exit maintenance mode?
Proceed as follows:
• If you did the Warming Up and Pre-Calibration successfully (section 4.5), and you
want to store the Pre-Calibration data before continuing with the Final Calibration:
⇒ Press
F5
YES.
When turning the Analyzer off and on again, it will show the message:
The instrument needs calibration.
Please contact your service center.
The calibration date and number will not be updated. You must continue with the Final
Calibration!
• To return to the Maintenance mode, if you want to repeat the complete calibration:
⇒ Press
F4
NO.
Now press
F1
until the display shows Warming Up (CL 0200):IDLE, and
calibrate the Analyzer, starting at section 4.5.
• If you want to exit and maintain the old calibration data:
Turn the Analyzer off.
