Fluke 433, 434, 435
Service Manual
6-4
6.4 Final Assembly Parts
See Table 6-1 and Figure 6-1 for the Final Assembly parts.
Table 6-1. Final Assembly Parts
Item Description Ordering Code
1 Top case assembly Fluke 433, 434, 435 (without LCD, without
window/decal, incl. sealing strips)
4022 244 98511
2 Display window/decal Fluke 433
Display window/decal Fluke 434
Display window/decal Fluke 435
0040 243 00031
0040 243 00071
0040 243 00161
3 Keypad 0040 243 00022
4 Keypad foil 0040 245 00022
5 Keypad support assembly 4022 244 98521
6 Display unit Color 4022 244 93261
Flat cable for display unit 4022 303 40111
7 Display mounting frame 4022 243 09773
Rubber buffer (self-adhesive, 2 pcs. at rear side of mounting frame) 4022 110 00511
Contact finger strip (self-adhesive, 1 pce. at rear of mounting
frame)
4022 244 94751
8 EJOT Pt self tapping screw 4022 244 92551
9 Decal set for input sockets, colored 0040 241 00412
9
9
Decal set for input sockets, black & white
Decal set for input sockets, as supplied to USA/Canada
0040 241 00401
0040 241 00761
10 Hang strap 946769
11 Combiscrew (black) to fix input cover 4022 244 90862
12 Input cover 0040 243 00041
13
Main PCA unit for Fluke 433/434 or 435. The Main PCA in this
Analyzer is only available to Fluke Service Centers due to the
programming that is necessary after installation.
---
14 Bottom case assembly, incl. isolation foil for optical RS232 port 4022 244 98501
15 Tilt stand (bail) 4022 244 98211
16 Strap 4022 244 98191
17 Strap holder (2 pcs per instrument) 4022 244 98201
18 Combi-screw Torx M3x10 (screw + split spring) 4022 244 91231
19 Combi-screw Torx M3x10 4022 325 42101
20 Battery Pack (see note below) BP190
21 Bottom holster 4022 244 98221
22 Combi-screw Torx M3x10 (screw + flat washer) 4022 244 91231
Note
The Analyzer contains a Ni-MH battery (item 20). Do not mix
with the solid waste stream. Spent batteries should be disposed
of by a qualified recycler or hazardous materials handler.
