70/73 English Instruction Sheet
Page
5
Diode Test
(G)
Forward Bias
Single Beep
Reverse Bias
Shorted
Open
or
Good Diode
Bad Diode
+
_
+
_
Bad Diode
+
_
Good Diode
+
_
hr7f.eps

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fluke 73 III and is the answer not in the manual?

Fluke 73 III Specifications

General IconGeneral
ContinuityYes
Diode TestYes
Safety RatingCAT III 600 V
Voltage DC600 V
Voltage AC600 V
Current DC10 A
Current AC10 A
Resistance32 MΩ
Battery Type9V
