Fluke SUPER-DAQ 1586A - Page 26

SUPER-DAQ Precision Temperature Scanner
Calibration Adjustment
21
Table 9. Adjustment Steps (cont.)
Step Value Range
Input
Signal
Description
Entry
Point
OHM
R100 100.0
Start calibration of FRES
100 Ω range
Y
R_100_1 100.0 Ω N
R_19_1 19.0 Ω N
R_0_1 0.0 Ω N
R1K 1.0E+3
Start calibration of FRES
1 kΩ range
Y
R_1K_2 1.0 kΩ N
R_190_2 190.0 Ω N
R_0_2 0.0 Ω N
R10K 10.0E+3
Start calibration of FRES
10 kΩ range
Y
R_10K_3 10.0 kΩ N
R_1_9K_3 1.9 kΩ N
R_0_3 0.0 Ω N
R100K 100.0E+3
Start calibration of FRES
100 kΩ range
Y
R_100K_4 100.0 kΩ N
R_19K_4 19.0 kΩ N
R_0_4 0.0 Ω N
R1M 1.0E+6
Start calibration of FRES
1 MΩ range
Y
R_1M_5 1.0 MΩ N
R_190K_5 190.0 MΩ N
R_100K_5 100.0 kΩ N
R_0_5 0.0 Ω N
R10M 10.0E+6
Start calibration of RES
10 MΩ range
Y
R_10M_6 10.0 MΩ N
R_1_9M_6 1.9 MΩ N
R_1_0M_6 1.0 MΩ N
R_0_6 0.0 Ω N
