1586A
Calibration Manual
22
Table 9. Adjustment Steps (cont.)
Step Value Range
Input
Signal
Description
Entry
Point
R100M 100.0E+6
Start calibration of RES
100 MΩ range
Y
R_100M_7 100.0 MΩ N
R_19M_7 19.0 MΩ N
R_0_7 0.0 Ω N
PRT
P400FR 400.0
Start calibration of PRT
400 Ω range
Y
P_400_FR 400.0 Ω N
P_200_FR 200.0 Ω N
P_0_FR 0.0 Ω N
THERM
T2K 2.2E+3
Start calibration of FTH
2 kΩ range
Y
T_1_9K_1 1.9 kΩ N
T_1_0K_1 1.0 kΩ N
T_190_1 190.0 Ω N
T_0_1 0.0 Ω N
T90K 90.0E+3
Start calibration of FTH
90 kΩ range
Y
T_100K_2 100.0 kΩ N
T_19K_2 19.0 kΩ N
T_10K_2 10.0 kΩ N
T_0_2 0.0 Ω N
T1M 90.0E+3
Start calibration of FTH
1 MΩ range
Y
T_1M_3 1.0 MΩ N
T_190K_3 190.0 kΩ N
T_100K_3 100.0 kΩ N
T_0_3 0.0 Ω N
