SUPER-DAQ Precision Temperature Scanner
Calibration Adjustment
25
Remote Programming Examples
This section gives examples of command sequences for several likely scenarios.
Start a Full Calibration
Table 10 shows an example for how to run a full calibration.
Table 10. Full Calibration Example
Command Action
CAL:SEC:STAT OFF,”1586” Disable the security for calibration.
CAL:STAR MAIN
Start MAIN calibration procedure, and show instruction of MAIN
calibration procedure.
CAL:NEXT Continue to show instruction of VDC calibration.
CAL:NEXT
Continue to perform VDC calibration.
After it is completed, show instruction to connect the calibrator to
the instrument for DCV calibration.
CAL:NEXT
Show instruction to ask for +100 mV signal input, and the
reference value.
CAL:NEXT 0.1
Continue to perform measurements for this point, after it is
completed, show instruction to ask for 0 V signal input and the
reference value.
CAL:NEXT 0
Continue to perform measurements for this point, after it is
completed, show instruction to ask for -100 mV signal input and
the reference value.
CAL:NEXT -0.1
Continue to perform measurements for this point, after it is
completed, calculate the calibration constants for dc 100 mV
range, then show instructions to ask for +1 V input signal and the
reference value (the first calibration point of next dc 1 V range).
… …
CAL:STOR Store the calibration constants.
CAL:ABOR Abort the calibration procedure.
