D-1
Appendix D
Camera Specifications and
Dimensions
Table D-1 lists the technical specifications for the TiR2, Ti45 and Ti40
models.
Table D-1. TiR2, Ti45 and Ti40 Specifications
Model Name
Ti45 and
TiR2 with
IR Fusion
Ti45 and
TiR2 without
IR Fusion
Ti40 with
IR Fusion
Ti40 without
IR Fusion
Imaging Performance
Detector 160 x 120 Focal Plane Array (FPA), vanadium oxide (VOX)
uncooled microbolometer.
Refresh Rate Cameras have either 7.5 Hz or 30 Hz refresh rate. Use the
Camera Info screen to determine the refresh rate for your
specific camera.
Spectral
Band
8 µm to 14 µm
Thermal
Sensitivity
≤ 0.080°C at 30°C ≤ 0.090°C at 30°C
Focusing Single Finger Manual Focus
Electronic 2x None
