Fluo DCT35IUINVR32 - Standard Accessories

10
GB
DC Inverter U-match Series Duct Type Unit
6
2.3 Standard Accessories
Indoor Unit Accessories
No. Name Appearance Q'ty Usage
1
Wired
Controller
1 To control the indoor unit
2
Nut with
Washer
4
To fix the hook on the cabinet of
the unit.
3 Nut 4
To be used together with the
hanger bolt for installing the unit
4 Washer 4
To be used together with the
hanger bolt for installing the unit
5 Insulation
1 To insulate the gas pipe
6 Insulation 1 To insulate the liquid pipe
7 Fastener 8 To fasten the sponge
8 Sponge 2 To insulate the drain pipe
9 Sponge
1
To insulate the Fresh air inlet
(Only for 16.0KW)
10
Removal-
Proof
screw Nut
1 To connect gas pipe
11
Removal-
Proof
screw Nut
1 To connect liquid pipe
Outdoor Unit Accessories
No. Name Appearance Q'ty Usage
1 Drain Plug
1 or
3
To plug the unused drain hole
2
Drainage
Connecter
1
To connect with the hard PVC drain
pipe
