FLX Babymaker - Assembly Instructions; Assembly Overview and Resources

14 www.x.bike
The Babymaker|OwnersManual
15www.x.bike
The Babymaker|OwnersManual
Figure7.SlidingtheCaliperontotheRotor
PRO Model
a.Carefullyslidethewheelin-betweenthe
forks,makingsuretocarefullyinsertthe
rotorin-betweenthebrakecalipers.
   Caliper
   Rotor
The steps outlined on the following page are extremely important! Riding
with an improperly secured wheel can cause serious injury or death. If
you can’t safely complete these steps, please take your eBike into a bike
shop for professional assistance.
3.Positionthewheelbetweenbothoftheforks.Resttheforksonthewheelsothat
theaxletsintheslotsasshownbelow.
Standard Model: Don’tforgettolockthebrakesbyturningtheknobinto 
 thedown/lockedposition,orbycompletingstep“b.”onthepreviouspageifyou
 hadtofullyloosenthebrakestotthewheel.
Figure9.LockingtheC-BrakesonStandardModelFigure8.PlacingtheWheel
Standard Model
a.Turntheknobonthebrakesintoanupwardpositiontounlockthemandmake
roomforthefrontwheel.
b.Ifthebrakepadsstillwon’tclearthewheel,useyour5mmallenkeytolosenthe
boltholdingyourbrakepadstogether.Slidethewheelin,thenpinchthebrakesto
closethem,pullthecabletight,andre-tightenthebolt.
Note: There are some slight variances in the instructions for the Standard
model and the PRO model. Be sure to follow the set of instructions that
correspond with your model to avoid improper assembly.
1.LocatetheQuickReleaseSkewer-it
willbelocatedintheaccessoriesbox.
Thisskewerwillhaveanendcap+spring
ononeend,andalever+springonthe
other.
2.Removetheplasticprotectorfromthe
bottomoftheforks.
Figure4.QuickReleaseSkewer
STEP 3: Secure the Front Wheel
Figure5.ReleasingtheBrakes Figure6.Re-TighteningtheBrakes
