FLYGT 4630 - Table of Contents

2
CONTENTS
Page Page
Operation ____________________________ 18
Before starting ___________________________ 18
During operation __________________________ 18
Care and maintenance _____________ 19
Safety precautions ________________________ 19
Service __________________________________ 19
Changing the oil __________________________ 22
Replacing the propeller ____________________ 23
Lifting device _____________________________ 24
Tools and accessories _____________ 25
Tools ___________________________________ 25
Start and control equipment ________________ 25
Seal protection ___________________________ 25
Flush protection __________________________ 25
Cutting rings _____________________________ 26
Cooling jacket ____________________________ 26
Fault tracing (Troubleshooting) ___ 27
Service log ___________________________ 30
Guarantee ____________________________ 3
Data plates interpretation __________ 4
Product description ________________ 5
Applications _____________________________ 5
Motor data _______________________________ 6
Design __________________________________ 7
Materials ________________________________ 9
Weights _________________________________ 9
Performance curves for PP _________________ 10
Transportation and storage________ 11
Installation ___________________________ 11
Safety precautions ________________________ 11
Handling equipment _______________________ 11
Mixer installation alternatives _______________ 12
Flange mounted mixer _____________________ 12
PP-pump installation ______________________ 13
Electrical connections _____________ 15
CLS and FLS sensors ______________________ 17
General Danger:
Non-observance given to safety
instructions in this manual, which
could cause danger to life have
been specifically highlighted with
this general danger symbol.
High Voltage:
The presence of a dangerous volt-
age is identified with this safety
symbol.
Identification of safety and warning
symbols
This “Installation, Care and Maintenance”
applies to the following versions of the
4600-series:
4630
4630.410, 4630.490,
PP4630.410, PP4630.490
4640
4640.410, 4640.490,
PP4640.410, PP4640.490
4650
4650.410, 4650.490,
PP4650.410, PP4650.490
4660
4660.410, 4660.490,
PP4660.410, PP4660.490
4670
4670.410, 4670.490,
PP4670.410, PP4670.490
4680
4680.410, 4680.490,
PP4680.410, PP4680.490
