Flymo Speedi-Mo 360VC Operator's Manual

Removing and fitting the blade:
Switch off, wait until the blade has stopped rotating and disconnect
from the mains electricity supply BEFORE attempting to remove or refit
the blade.
Always handle the blade with care – sharp edges could cause injury.
USE GLOVES.
Removing the blade:
1. To remove the blade bolt, hold the blade firmly with a gloved hand
and with a spanner, loosen the blade bolt by turning it anti-clockwise
(Fig. F).
2. Remove the blade bolt, washer and blade.
3. Inspect for damage and clean as necessary.
Renew your metal blade after 50 hours mowing or 2 years,
whichever issooner, regardless of condition. If the blade is cracked
ordamaged replace it with a new one.
To fit the blade:
1. Fit the blade to the shaft with the sharp edges of the blade pointing
away from the shaft.
2. Re-assemble blade bolt through the washer and the blade.
3. Hold the blade firmly with a gloved hand and tighten the blade bolt
firmly with a spanner. Do not over tighten.
To clean the lawnmower:
DANGER! Risk of injury!
Risk of injury and risk of damage to the product.
v Do not clean the product with water or with a water jet
(in particular high-pressure water jet).
v Do not clean with chemicals including petrol or solvents.
Some can destroy critical plastic parts.
IMPORTANT!
After receiving your lawnmower from the manufacturer, it is
very important that you keep your unit clean. Grass clippings
left in any of the air intakes or under the deck could become
apotential fire hazard.
1. Disconnect lawnmower from the mains electricity supply.
2. Remove grass from under the deck with a brush.
3. Using a soft brush, remove grass clippings from all air intakes, the
discharge chute and the grassbox.
4. Using a soft brush, remove grass clippings from the vision window
(ifequipped).
5. Wipe over the surface of your lawnmower with a dry cloth.
5. STORAGE
To put into storage:
The product must be stored away from children.
Storing your cable:
Your electric cable can be wrapped around hooks to enable tidy and
safe storage.
Storing your lawnmower:
Store in a dry place where your lawnmower is protected from damage.
Loosen the wing knobs to enable the handles to be folded over the
product ensuring that the upper handle is supported.
At the end of the mowing season:
1. Replace bolts, nuts or screws, if necessary.
2. Clean your lawnmower thoroughly.
3. Make sure that the electric cable is stored correctly to prevent damage.
Disposal:
(in accordance with RL2012/19/EC / S.I. 2013 No. 3113)
The product must not be disposed of to normal household
waste. It must be disposed of in line with local environmental
regulations.
IMPORTANT!
v Dispose of the product through or via your municipal recycling
collection centre.
6. TROUBLESHOOTING
DANGER! Risk of injury!
Cut injury when the product starts accidentally.
v Wait for the blade to stop, disconnect the product from the
mains and use gloves before you troubleshoot the product.
Fails to operate:
1. Is the correct starting procedure being followed?
See To start the lawnmower.
2. Is the power turned on?
3. Check the fuse in the plug. Replace if blown.
Poor grass collection:
1. Disconnect from the mains electricity supply.
2. Clean the outside of the air intakes, the discharge chute and the
underside of the deck.
3. Raise to a higher height of cut. See Adjusting the cutting height.
Excessive vibration:
1. Disconnect from the mains electricity supply.
2. Check that the blade is fitted correctly.
3. If the blade is damaged or worn, replace it with a new one.
Lawnmower becomes heavy to push:
1. Disconnect from the mains electricity supply.
2. In long grass or uneven ground, the height of cut should be raised to
ahigher position. See Adjusting the cutting height.
3. Check that the wheels and rollers can rotate freely.
For any other malfunctions please contact the Husqvarna UK Ltd. Customer
Service. Repairs must only be done by Husqvarna UK Ltd. service departments
or specialist dealers approved by FLYMO.
7. TECHNICAL DATA
Electric Rotary Lawnmower Unit Value
Speedi-Mo 360VC
9676633-xx
Rated power kW 1.5
Mains voltage V (AC) 230
Mains frequency Hz 50
Speed of rotation cutting blade rpm 3,600
Cutting width cm 36
Cutting height adjustment mm 20 – 60
Volume of grass box l 30
Weight kg 11.5
Sound pressure level L
pA
1)
Uncertainty k
pA
dB (A)
87
1.84
Sound power level L
WA
2)
:
measured / guaranteed
Uncertainty k
WA
dB (A)
94 / 96
2.0
Hand / arm vibration a
vhw
1)
Uncertainty k
vhw
m/s
2
2.3
1.5
Measuring process complying with:
1)
EN 60335-2-77
2)
RL 2000/14/EC / S.I. 2001 No.1701
NOTE: The stated vibration emission value has been measured according to
astandardized test procedure and can be used for comparison of one electric
power tool with another. It can also be used for preliminary evaluation of expo-
sure. The vibration emission value can vary during actual use of the electric power tool.
8. ACCESSORIES
FLYMO Replacement Blade
for Speedi-Mo 360VC
As replacement for blunt blade. Part no.: 590605190
Art. FLY071
6
