16
Connector Function
CN1/2 SATA power connector
CN3 EC debug port
CN4 Printer connector
CN5 M.2 WiFi socket
CN6 SDV connector
CN8/9/10 USB2.0 connector
CN11 COM4 connector
CN12 Inverter connector
CN13 eDP connector
CN14 Bedside connector
CN15 DP/HDMI Connector
CN16 DICOM Connector
CN17 DICOM for LVDS_VDD_EN
CN18 LVDS connector
CN19 SDR connector
CN20 ON/OFF & Power LED connector
CN21 Build in Speaker/MIC connector
CN22 Build in speaker(left)
CN23 Build in speaker(right)
CN24 Audio jack
CN25 Charger board power connector
CN26 Charger board function connector
CN27/28 LAN2 LED connector for by pass no isolator
PCIE1 PCIE X4 slot connector
FAN1 FAN connector
HDMI HDMI connector
AUX1 MIC in jack
PWR1/PWR2 DC Jack
RJ11_1 Cash drawer connector
RJ45_1 LAN1 connector
RJ45_2 COM1/COM2_RS232/422/485
RJ45_3 LAN2 connector
DiMM_A1 / DIMM_B1 DDR4 SO-DIMM
SATA0/SATA1 SATA connector
BAT1 Battery socket
USB1/USB2 USB3.0
USB3 Isolator USB connector
COM1 CRT connector
SW1 Power button
MINI_PCIE1 Mini PCIe WiFi socket
JP1 LCD ID setting
JP2 Clear CMOS
JP3 Hareware reset
JP4/5 isolator USB speed select
JP6 Audio Mono setting
7-2. Connectors & Functions
