31
6-3-2 Connectors & Functions
Connector Function
CN6/CN7 HDD Power
CONN
CN8 Power Button
CN10 DVI CONN
CN11 To Front I/O Board
CN12 USB CONN
CN18 Printer CONN
CN19 Line Out
CN20 Batter
y
CONN
DDR3_A1 DDR3 DIMM1
FAN_CPU3
FAN CONN
FAN_SYS3 FAN CONN
PS1 PS2 Port
PWR3
/
4/5
DC-JACK
RJ11_3 Cash Drawer
Port
RJ45_3 COM1~4
Port
RJ45_4 LAN Port
SATA1
/
2 SATA CONN
SATA3 To SATA Dockin
g
Board
SW3 Power Button
USB4
/
5 USB Port
VGA3 VGA Port
JP3 Cash Drawer Power Settin
g
JP4 S
y
stem Indicator
JP5 COM3/COM4 Power Settin
g
JP12 ME Update
