Flyzone Tidewater - Contents; Assemble the Model; Assemble the Fuselage

4
ASSEMBLE THE MODEL
Before starting to assemble the Tidewater Sea Plane, we
recommend charging the fl ight battery. Then, when you are
ready to setup the radio system, the fl ight battery can be used
to power the receiver. Refer to the charging instructions on
page 9.
Assemble the Fuselage
❏
1. Insert the “z-bend” end of the elevator pushrod wire into
the outer hole of the servo arm.
❏
2. A brass screw lock connector is pre-installed in the
bottom of the elevator. Loosen the screw and slide the screw
lock connector onto the wire.
4
CONTENTS
1
6
8
9
2
4
7
3
3
5
1. Fuselage
2. Wing
3. Tip Floats (1 pair)
4. Stabilizer and
Elevator
5. Motor Pod and
Motor
6. Spinner
7. Prop Adapter
8. ESC
9. Prop
