FMI V) DVF42NH - Burner Assembly

www.fmiproducts.com
125078-01B 33
KEY
NO. PART NO. DESCRIpTION QTY.
1 122839-02 Burner Tube, 36" • • • 1
122839-01 Burner Tube, 42" • • • 1
2 ** Front Burner Assembly • • • • • • 1
3 112371-15 Rear Orice, #47 NG • • 1
23100 Rear Orice, #56 Propane/LP • 1
23101 Rear Orice, #44 NG • • 1
23567 Rear Orice, #55 Propane/LP • 1
4 11214 Bulkhead Fitting • • • • • • 2
5 116573-01 Washer, Flt 7/8"x1
1
/
4
" OD • • • • • • 5
6 ** Log/Burner Base • • • • • • 1
7 122122-01 Pilot, NG • • 1
122122-02 Pilot, Propane/LP • • 1
123783-01 Pilot, NG High Altitude • • 1
8 ** Pilot Shield • • • • • • 1
9 14296 Elbow, Street 3/8" • • • • • • 1
10 112371-15 Front Orice, #47 NG • • 1
23100 Front Orice, #56 Propane/LP • 1
24771 Front Orice, #42 NG • • 1
23100 Front Orice, #56 Propane/LP • 1
11 ** Base • • • • • • 1
12 114027-01 Grommet SC 1/2" ID 1
1
/
16
" OD • • • • • • 1
13 14399 90° Elbow, Brass 3/8" Tube x 3/8" NPT • • • • • • 2
14 111817-06 Flextube Dormont, 3/8" Dia. x 11" • • • • • • 1
15 111817-09 Flextube Dormont, 3/8" Dia. x 24" • • • • • • 1
16 ** Pilot Bracket • • • • • • 1
17 122116-01 Dexen Valve, NG • • 1
122117-01 Dexen Valve, LP • • 1
123782-01 Dexen Valve, NG High Altitude 3.8" • • 1
18 112823-01 Brass T-Fitting 3/8" • • • • • • 1
19 122118-01 Control Module • • • • • • 1
20 122119-01 Battery Relay • • • • • • 1
21 122121-01 Battery Pack • • • • • • 1
22 122860-01 Valve Bracket • • • • • • 1
23 120066-01 Remote Receiver • • • • • • 1
24 ** Log Assembly, 36" • • • 1
** Log Assembly, 42" • • • 1
25 123560-01 Base Valve • • • • • • 1
PARTS AVAILABLE NOT SHOWN
122120-01 Wire Harness Relay • • • • 1
122123-01 AC Adapter 3V • • • • 1
112799-01 Ember Flakes Kit • • • • 1
26839 Rockwool • • • • 1
GA6060 Lave Rock Kit • • • • 1
VTA-LS5-2 Log Scrap Kit • • • • 1
120065-01 Hand-Held Remote Transmitter • • • • 1
14253 30" Flex Line • • • • 1
PARTS
BURNER ASSEMBLY
This list contains replaceable parts used in your replace. When ordering parts, follow the
instructions listed under Replacement Parts on page 36 of this manual.
(V)DVF36N(H,S)
(V) DVF36P(H,S)
(V)DVF42N(H,S)
(V)DVF42P(H,S)
DVF36N(H,S)-HA
DVF42N(H,S)-HA
